From Push to Production: Automated Deployments to K3s with GitLab CI/CD (Real-World Guide)

You’ve got a K3s cluster and a GitLab instance. You push code and—ideally—your app rolls out automatically. In practice, you might hit a few snags: pipelines not triggering, service ports clashing, or images refusing to pull with an ominous ImagePullBackOff (401 Unauthorized). This guide shows a clean, repeatable setup and the exact fixes that work in real life—with anonymized URLs/IPs so you can drop this straight onto your blog.

Environment used in this guide (genericized)

• K3s cluster: accessible at <CLUSTER_NODE_IP>
• GitLab: https://<GITLAB_HOST> with a private registry https://<REGISTRY_HOST>
• Runner host: separate Linux box (Podman or Docker installed; kubectl access to K3s)
• Projects: my-backend (API) and my-frontend (UI)

Architecture at a glance

• GitLab CI/CD builds the image → pushes to GitLab Container Registry → applies Kubernetes manifests to K3s.
• Services/ports in this example:
  • Backend my-backend-service: NodePort 30080 → http://<CLUSTER_NODE_IP>:30080
  • Frontend my-frontend-service: NodePort 30081 → http://<CLUSTER_NODE_IP>:30081

Prerequisites

1. Runner can reach the cluster (job image has kubectl and a valid kubeconfig). In many self-hosted setups, you may mount or inject kubeconfig via CI variable KUBE_CONFIG.
2. GitLab Container Registry is enabled; projects push images to https://<REGISTRY_HOST>/<group>/<project> (private).
3. Kubernetes manifests (Deployment + Service) exist in your repo.
4. Optional GitLab variables often used in templates: CI_REGISTRY_USER, CI_REGISTRY_PASSWORD, CI_REGISTRY, KUBE_CONFIG.

Security tip: Mask & protect secrets, and scope them per environment where possible.

Kubernetes manifests (example)

Deployment (frontend)

Use labels for easy selection and a container listening on port 80. Replace the image with your registry path.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-frontend
spec:
  replicas: 2
  selector:
    matchLabels:
      app: my-frontend
  template:
    metadata:
      labels:
        app: my-frontend
    spec:
      containers:
        - name: my-frontend
          image: <REGISTRY_HOST>/<GROUP>/<PROJECT>:latest
          ports:
            - containerPort: 80
      imagePullSecrets:
        - name: regcred

Service (avoid port conflicts)

Pick a NodePort that doesn’t collide with other services (here, 30081 for the frontend).

apiVersion: v1
kind: Service
metadata:
  name: my-frontend-service
  labels:
    app: my-frontend
spec:
  type: NodePort
  selector:
    app: my-frontend
  ports:
    - port: 80
      targetPort: 80
      nodePort: 30081

GitLab CI/CD: two proven patterns

A) Minimal Docker-in-Docker pipeline

This approach builds and pushes with docker:dind, then deploys with kubectl:

stages:
  - build
  - deploy

variables:
  DOCKER_IMAGE_TAG: "$CI_COMMIT_SHORT_SHA"
  KUBE_NAMESPACE: "default"

build:
  stage: build
  image: docker:latest
  services: [docker:dind]
  script:
    - docker build -t "$CI_REGISTRY_IMAGE:$DOCKER_IMAGE_TAG" .
    - docker push "$CI_REGISTRY_IMAGE:$DOCKER_IMAGE_TAG"
    - docker tag "$CI_REGISTRY_IMAGE:$DOCKER_IMAGE_TAG" "$CI_REGISTRY_IMAGE:latest"
    - docker push "$CI_REGISTRY_IMAGE:latest"

deploy:
  stage: deploy
  image: bitnami/kubectl:latest
  script:
    - sed "s|<IMAGE_NAME>|$CI_REGISTRY_IMAGE:$DOCKER_IMAGE_TAG|g" k8s/deployment-template.yaml > k8s/deployment.yaml
    - kubectl -n "$KUBE_NAMESPACE" apply -f k8s/deployment.yaml
    - kubectl -n "$KUBE_NAMESPACE" apply -f k8s/service.yaml
    - kubectl -n "$KUBE_NAMESPACE" rollout status deployment/my-frontend --timeout=180s

B) Podman + explicit workflow rules (great when pushes don’t trigger)

Adding workflow rules to allow push and web sources ensures pipelines start on push and via manual triggers:

stages:
  - build
  - push
  - deploy

variables:
  IMAGE_NAME: "$CI_REGISTRY_IMAGE:$CI_COMMIT_SHORT_SHA"
  KUBE_NAMESPACE: "default"

workflow:
  rules:
    - if: $CI_PIPELINE_SOURCE == "push"
    - if: $CI_PIPELINE_SOURCE == "web"

build-frontend:
  stage: build
  script:
    - npm ci
    - npm run build
    # auth for Podman to push to the GitLab registry (using CI_JOB_TOKEN)
    - mkdir -p ~/.docker
    - AUTH=$(echo -n "$CI_REGISTRY_USER:$CI_JOB_TOKEN" | base64 | tr -d '\n')
    - echo "{\"auths\":{\"$CI_REGISTRY\":{\"auth\":\"$AUTH\"}}}" > ~/.docker/config.json
    - podman build -t "$IMAGE_NAME" .
  artifacts:
    paths: [build/]

push-image:
  stage: push
  needs: [build-frontend]
  script:
    - podman login "$CI_REGISTRY" -u "$CI_REGISTRY_USER" -p "$CI_JOB_TOKEN"
    - podman push "$IMAGE_NAME"

deploy:
  stage: deploy
  needs: [push-image]
  image: bitnami/kubectl:latest
  script:
    # (Optional) create/refresh the imagePull secret
    - |
      kubectl -n "$KUBE_NAMESPACE" create secret docker-registry regcred \
        --docker-server="$CI_REGISTRY" \
        --docker-username="$CI_REGISTRY_USER" \
        --docker-password="$CI_JOB_TOKEN" \
        --docker-email="ci@example.com" \
        || echo "regcred already exists"
    - kubectl -n "$KUBE_NAMESPACE" set image deployment/my-frontend my-frontend="$IMAGE_NAME"
    - kubectl -n "$KUBE_NAMESPACE" rollout restart deployment/my-frontend

Verifying a deployment after push

After the pipeline completes, confirm that the new Pods are up and the Service points to them:

# Watch rollout
kubectl -n <NAMESPACE> rollout status deployment/my-frontend

# See Pods and their status
kubectl -n <NAMESPACE> get pods -l app=my-frontend

# Describe a failing Pod if needed
kubectl -n <NAMESPACE> describe pod <pod-name>

# Check Services and endpoints
kubectl -n <NAMESPACE> get svc
kubectl -n <NAMESPACE> get endpoints my-frontend-service

To verify connectivity end-to-end:

# From outside the cluster (NodePort)
curl -fsSI "http://<CLUSTER_NODE_IP>:30081/health"

The big one: fixing ImagePullBackOff (401 Unauthorized)

A very common failure during rollout looks like this:

Failed to pull and unpack image ".../<group>/<project>:<sha>":
failed to authorize: failed to fetch oauth token: unexpected status ...
401 Unauthorized

This means the cluster failed to authenticate against the private GitLab Registry. Typical root causes:

• The imagePullSecret (regcred) is missing, outdated, or created with credentials that can’t read the registry.
• The pipeline pushes images using CI_JOB_TOKEN, but your cluster later pulls them using different credentials (or none). Result: 401.

How to fix it (three reliable options)

1. Use a Deploy Token or Personal Access Token with read_registry
   • Create a token in GitLab with read_registry.
   • Recreate regcred on the cluster with that token:

     kubectl -n <NAMESPACE> delete secret regcred || true
     kubectl -n <NAMESPACE> create secret docker-registry regcred \
       --docker-server=<REGISTRY_HOST> \
       --docker-username="<DEPLOY_TOKEN_USERNAME_OR_USER>" \
       --docker-password="<TOKEN_WITH_read_registry>"


   • Ensure your Deployment uses imagePullSecrets: [{ name: regcred }].
2. Use the built-in CI_REGISTRY_USER + CI_JOB_TOKEN (if permitted)
   Some GitLab setups permit CI_JOB_TOKEN for pulls from the cluster; others don’t. If you see repeated 401s, prefer option 1.
3. Pre-configure registry auth at the cluster level
   On self-hosted K3s, you can configure registry credentials once (e.g., via K3s’ registry config) so every node can pull from your GitLab registry without per-namespace secrets.

Sanity checks after the fix

kubectl -n <NAMESPACE> get secret regcred -o yaml   # confirm it exists & is fresh
kubectl -n <NAMESPACE> rollout restart deploy/my-frontend
kubectl -n <NAMESPACE> get pods -l app=my-frontend -w

Avoiding port collisions

If your backend already uses NodePort 30080, keep the frontend on a different port (e.g., 30081) to avoid clashes. Later, introduce an Ingress and TLS so you can expose multiple apps cleanly under https://app.<your-domain> paths or subdomains.

When a pipeline won’t trigger on push

If a push doesn’t start a pipeline but manual trigger works, add workflow rules like:

workflow:
  rules:
    - if: $CI_PIPELINE_SOURCE == "push"
    - if: $CI_PIPELINE_SOURCE == "web"

This ensures manual and automatic triggers behave as expected.

Post-deploy health checklist (copy/paste)

• kubectl -n <NAMESPACE> rollout status deploy/<name> — rollout completed?
• kubectl -n <NAMESPACE> get pods -l app=<label> — new Pods Ready=1/1?
• kubectl -n <NAMESPACE> logs deploy/<name> --tail=100 — any runtime errors?
• kubectl -n <NAMESPACE> get svc — is the expected NodePort/LoadBalancer exposed?
• curl http://<CLUSTER_NODE_IP>:<nodePort>/health — basic health responder ok?

Quick FAQ

Do I need KUBE_CONFIG as a CI variable?
Only if your runner job doesn’t already have a working kubeconfig. A common pattern is to store a base64-encoded kubeconfig in a masked variable KUBE_CONFIG and write it to disk during the job:

echo "$KUBE_CONFIG" | base64 -d > kubeconfig
export KUBECONFIG=$PWD/kubeconfig

Why did the old Pod stay up while the new one failed?
Kubernetes keeps the old, healthy ReplicaSet available while the new ReplicaSet is in ImagePullBackOff. The rollout completes only after the new image pulls and Pods become Ready.

What’s the fastest way to test registry auth from the cluster?
Recreate regcred with a token that has read_registry, reference it in the Deployment, then rollout restart. Watch for image pulling to succeed.

Wrap-up

A smooth GitLab → K3s pipeline comes down to three things:

1. A sane pipeline (Docker or Podman) with explicit workflow rules.
2. Clear Kubernetes manifests (Deployment + Service), with unique, documented ports.
3. Registry pull credentials that actually work for the cluster (fixing the 401 ImagePullBackOff).

With these locked in, every push becomes a predictable rollout on your K3s cluster—no surprises.
